Horizontal Jig Boring Machines

The FEMCO BMC series offers table load capacities ranging from 13,889 lbs on the BMC-110R2 up to 40,000 lbs on the BMC-100HT and BMC-110T3 models. The BMC-135TN and BMC-135TNL support up to 33,000 lbs. All models feature a Full B-Axis Rotary Table for versatile workpiece positioning.

All FEMCO horizontal boring mills in the BMC series are equipped with FANUC CNC control systems. Depending on the model, these include the FANUC OiMF, FANUC 31i-B, or the advanced FANUC Artificial Intelligence Contour Control (AICC), which delivers superior precision and efficiency for complex CNC machining operations.

X-axis travel across the FEMCO BMC series ranges from 55.12 inches on the BMC-110R1 up to 157.4 inches on the BMC-135TNL, making these machines suitable for small to very large workpieces. The BMC-100HT, BMC-110T3, and BMC-110R3 offer up to 118 inches of X-axis horizontal table travel.

Spindle power ranges from 35 HP to 50 HP across the BMC series. Spindle speeds vary by model: the BMC-110R1, BMC-110R2, BMC-110R3, and BMC-110T3 reach 2,500 RPM; the BMC-135TN and BMC-135TNL reach 3,000 RPM; and the high-speed BMC-100HT achieves up to 8,000 RPM for precision high-speed machining applications.

Yes, most FEMCO BMC series horizontal boring mills include a 60-tool Automatic Tool Changer (ATC), enabling efficient, uninterrupted machining operations with rapid tool changeover. This significantly reduces cycle times in production environments and supports a wide variety of boring, milling, drilling, and threading operations without manual intervention.

Yes. Every FEMCO horizontal boring machine purchased through T.R. Wigglesworth Machinery Co. includes delivery, installation, and operator training services. Technical support is also available post-installation. The company serves customers across all 50 U.S. states and Canada, ensuring comprehensive support from order to operation.
