Used Floor Type CNC Horizontal Boring Mills

The FEMCO BMC Series offers spindle power from 35 HP to 50 HP depending on the model. Spindle speeds range from 2,500 RPM in standard boring configurations up to 8,000 RPM in the high-speed BMC-100HT model, which uses FANUC AI Contour Control for precision high-speed machining applications.

Table load capacities across the FEMCO BMC Series range from 13,889 lbs on the BMC-110R2 up to 40,000 lbs on models like the BMC-100HT and BMC-110R3. The BMC-135TN and BMC-135TNL models support up to 33,000 lbs via a Full B-Axis Rotary Table, suitable for workpieces up to 20 tons.

All FEMCO BMC Series horizontal boring mills are equipped with FANUC CNC control systems. Depending on the model, controls include FANUC OiMF, FANUC 31i-B, and FANUC Artificial Intelligence Contour Control (AICC). Linear scales on X, Y, and Z axes are standard features ensuring high positioning accuracy.

X-axis travel ranges vary by model: the BMC-110R1 offers 55.12 inches, the BMC-110R2 provides 78.74 inches, the BMC-135TN and BMC-100HT extend to 118 inches, and the BMC-135TNL offers the longest travel at 157.4 inches — making it ideal for machining large structural components and extended weldments.

Yes. All FEMCO BMC Series horizontal boring mills purchased through T.R. Wigglesworth Machinery Co. include delivery, installation, and operator training services. Technical support is also available. Contact T.R. Wigglesworth directly for specific shipping timelines, site preparation requirements, and warranty details relevant to your location.

CNC horizontal boring mills are widely used in heavy manufacturing, aerospace and defense, precision manufacturing, energy and power generation, and mold machining. These machines are especially critical wherever large, complex workpieces — such as housings, frames, engine components, or structural weldments — require tight-tolerance multi-axis machining in a single setup.
