Clausing Covel Surface Grinders

Manual models use hydraulic longitudinal table movement with handwheel-controlled crossfeed, offering hands-on operator control. Automatic models add a Delta PLC conversational digital controller with a 7.2" color touch screen, enabling programmable up/down head positioning, auto crossfeed increments, and greater process repeatability for production environments.

All Clausing Covel Surface Grinders require three-phase power, available at 230 or 460 volts. Facilities not equipped with these voltage levels will require a step-up or step-down transformer. Spindle motor horsepower ranges from 2 hp to 7.5 hp depending on the model selected.

Clausing Covel Surface Grinders feature high-grade cast iron construction with heavy walls and reinforced honeycomb ribbing, providing exceptional rigidity and vibration dampening. The V and Flat ways are hand-scraped and coated with Turcite B for superior wear resistance, complemented by an automatic lubrication system.

Across the CSG Series, compatible grinding wheel diameters range from 8" to 14", with wheel widths from 0.5" to 2" and bore sizes from 1.25" to 5". The specific wheel specifications depend on the model; for example, the CSG3A1224 uses a 12" diameter wheel with a 1.25" width and 3" bore.

All Clausing Covel Surface Grinders come with a 1-year limited manufacturer's warranty. Support is provided through an independently operated Clausing Service Center stocking over 80,000 parts, with 95% of orders shipped within 24 hours. Highly qualified technicians are available for both phone-based and on-site technical support.

These grinders are widely used across precision manufacturing, aerospace and defense, medical device manufacturing, mold machining, and general machine shop operations. They are suited to any environment requiring tight surface finish tolerances on metallic components, tooling, fixtures, and production parts.
