Clausing CSG-2480 24" x 80" Surface Grinder

Automatic models in the CSG series are equipped with a Delta PLC conversational digital controller featuring a 7.2" color touch screen. This allows operators to program up/down head positioning and manage grinding cycles with precision, reducing setup time and improving repeatability in production environments.

The machine is built from high-grade cast iron with heavy walls and reinforced honeycomb ribbing for exceptional rigidity and vibration dampening. The V and Flat ways are coated with Turcite B for excellent wear resistance, ensuring long-term dimensional accuracy and smooth table movement under heavy grinding loads.

The CSG series offers spindle motor power ranging from 2 hp to 7.5 hp depending on the model, with spindle speeds between 1,750 rpm and 3,450 rpm. The spindle uses preloaded precision angular contact ball bearings and NU/NN type roller bearings to maintain accuracy and minimize runout during operation.

The CSG series accommodates grinding wheels with diameters ranging from 8" to 14", widths from 0.5" to 2", and bore sizes from 1.25" to 5". Selecting the appropriate wheel specification depends on the material, surface finish requirement, and depth of cut needed for your specific metalworking application.

Yes, the Clausing CSG-2480 includes a 1-year limited warranty provided by the manufacturer. T.R. Wigglesworth Machinery Co. supports this with access to Clausing's service center, which maintains over 80,000 parts in stock and fulfills approximately 95% of orders within 24 hours to minimize downtime.

The CSG-2480 is well-suited for aerospace and defense, medical device manufacturing, mold machining, and heavy precision manufacturing. It excels at high-accuracy surface grinding in machine shops and production facilities requiring consistent flatness, parallelism, and surface finish across large workpieces in both manual and automatic grinding cycles.
