ACER SUPRA VMC-2240XL VERTICAL MACHINING CENTER

FEATURES:

* FANUC Oi MC 3-AXIS CNC CONTROL W/ CONVERSATIONAL Oi GUIDE (OPTIONAL)
* 24-POCKET ARM TYPE SIDE MOUNT AUTOMATIC TOOL CHANGER
* CENTRAL AUTOMATIC LUBE SYSTEM
* C3 BALL SCREWS AND DOUBLE-END THRUST BEARING SET (X/Y/Z)
* AIR GUN WITH REAR FLOOD COOLANT SYSTEM & ENLARGED COOLANT TANK
* HALOGEN WORK LIGHT
* FULL ENCLOSURE SPLASH GUARD
* HIGH SPEED MACHINING FUNCTION
* LINEAR WAY ON X, Y, Z AXES
* LASER CHECK & BALL BAR CALIBRATION

SPECIFICATIONS:

15 HP (30-MIN), 10 HP CONTINIOUS DIGITAL SPINDLE MOTOR / DRIVE
60 - 8000 RPM SPINDLE SPEED
CAT #40 / BT #40 SPINDLE
PRECISION SPINDLE W/ FIVE ABEC-7 HEARINGS
RUGGED 42" X 19.6" TABLE WITH LOAD CAPACITY 1320 LBS
3 T-SLOTS, 9.9" APART W/ 0.708" WIDTH
X/Y/Z TRAVEL: 40" X 20" X 20"
SPINDLE NOSE TO TABLE: 4.72" - 24.8"
SPINDLE TABLE CENTER TO Z SLIDEWAY: 24.68"
X/Y/Z RAPID RATE: 945/945/945 IPM (OPTIONAL 1181/1181/1181)
CUTTING FEED RATE: 200 IPM
POSITIONING ACCURACY / REPEATABILITY: +/- 0.0002", +/- 0.00012"
FLOOR SPACE (L x W x H): 98" x 94" x 102"
MACHINE PACKING / FOUNDATION: 110" X 91" X 97" / 115" X 100" X 100"
MACHINE WEIGHT NET / GROSS: 12,100 / 12,716 LBS
ELECTRICAL SUPPLY: 230/3/60
AIR REQUIRED: 96 PSI

CONTROL SOFTWARE FEATURES:

* 3-AXIS CONTOURING: AI CONTOUR CONTROL; SPINDLE AND SERVO HRV CONTROL
* CONTROL AI PREVIEW FUNCTION
* HIGH SPEED MACHINERY
* SCALING / ROTATING / MIRROR FUNCTION / HELICAL INTERPOLATION
* AUTOMATIC CORNER OVER-RIDE
* DWELL FUNCTION; MULTI0G FUNCTION; SINGLE BLOCK
* POLAR COORDINATE COMMAND REGISTERED PROGRAMS
* TOOL LENGTH MEASUREMENT; TOOL RADIUS COMPENSATION
* DRY RUN; BACKGROUND EDIT
* TEACH MODE; HELP GRAPHICS
* CONVERSATIONAL G-CODE HELP MENU Oi GUIDE (OPTIONAL)
* SUB PROGRAMMING
* ABS/INC PROGRAMMING; DECIMAL POINT PROGRAMMING
* SPINDLE SPEED OVER-RIDE; RIGID TAPPING
* AUTOMATIC RETURN TO REFERENCE POINT; AUTOMATIC COORDINATE SETTING
* G25-G59 FEATURE OFFSET; TOOL LIFE MANAGEMENT
* ALARM DISPLAY; CLOCK FUNCTION; RS-232
* PART PROGRAM STORAGE LENGTH 640 M
* MEMORY CARD INPUT/OUTPUT; 8.3" COLOR LCD SCREEN
* ETHERNET CARD (OPTIONAL)
* COMMUNICATE WITH CAD-CAM SOFTWARE SYSTEM

OPTIONAL ACCESSORIES:

ONE DAY ON-SITE TRAINING
"SPIDERCOOL" INDEXING COOLANT NOZZLE SYSTEM
"RENISHAW" TOOL TOUCH PROBE (TS27R) W/ SOFTWARE
"RENISHAW" 3-D PART PROBE (OMP40) W/ SOFTWARE & HOLDER
CHIP CONVEYOR (BELT-TYPE)
CHIP CONVEYOR (AUTOMATIC AUGER-TYPE)
SPINDLE CHILLER (FOR 12,000 RPM SPINDLE)
12,000 RPM SPINDLE & MOTOR
COOLANT-THRU-SPINDLE SYSTEM W/ COOLANT PUMP (300PSI)
6" ROTARY TABLE W/ INTEGRATED DRIVE & MOTOR
8" ROTARY TBALE W/ INTEGRATED DRIVE & MOTOR
10" ROTARY TABLE W/ INTEGRATED DRIVE & MOTOR
TAILSTOCK FOR ROTARY TABLE OPTION
8" 3-JAW CHUCK FOR ROTARY TABLE
UPGRADE TO 440 VOLTAGE TRANSFORMER
FOR 4TH AXIS READY, ADDITIONAL DRIVE & MOTOR ONLY

*** ABOVE PRICES ARE BASED ON F.O.B. NEW JERSEY
*** PRICES AND DESIGNS ARE SUBJECT TO CHANGE WITHOUT NOTICE
*** MANUFACTURER RESERVES THE RIGHT TO MODIFY THE DESIGN WITHOUT NOTICE
*** 1 YEAR PARTS & LABOR ON MACHINE & CONTROL
