SPECIFICATIONS:
HEADSTOCK V130
SPINDLE DIAMETER...................................................... 5.11"
MAXIMUM SPINDLE SPEED................................................. 3000 RPM
SPINDLE MOTOR POWER (S1 cont./S6-40%)................................. 49.6/60.3 HP
MAX. SPINDLE TORQUE (S1 cont./S6-40%)................................. 1630/1981 LB-FORCE0 FT
WORKING RANGE OF THE AXES
MAX. FEEDRATE ALL AXES................................................ 314.96 IN/MIN
MEASURING DEVICE OF THE X, Y, AND Z AXES.............................. ELECTRO-OPTICAL LINEAR (ABSOLUTE)
MEASURING DEVICE OF THE B AXIS........................................ ELECTRO-OPTICAL ANGULAR (ABSOLUTE)
MEASURING DEVICE OF THE W AXIS........................................ INTERNAL MOTOR ENCODER (ELECTRO-OPTICAL LINEAR AS AN OPTION)
MEASURING DEVICE OF THE SPINDLE (C AXIS).............................. MAGNETIC DIRECT ROTARY ENCODER
ROTARY TABLE
MAX. WORKPIECE WEIGHT................................................. 26,455 LB
CLAMPING T-SLOTS SIZE................................................. 22H8 (CENTRAL), THE REST 22H12
NUMBER OF SLOTS....................................................... 11/2 PC
MAX. RANGE OF WORKING FEEDS ON THE B AXIS............................. 0-2 RPM
FAST FEED B AXIS...................................................... 2 RPM
BASIC POWER REQUIREMENTS
TOTAL INSTALLED LOAD.................................................. 96-120
OPERATING VOLTAGE..................................................... 3 x 400
OPERATING VOLTAGE ALLOWANCE........................................... +/- 5
CONTROL LOW VOLTAGE................................................... 24
OPERATING VOLTAGE FREQUENCY........................................... 50/60
MAX. NOISE LEVEL AT OPERATORS LOCATION LAeq........................... 80
MAX. NOISE LEVEL AT OPERATORS LCOATION................................ 80
OPERATING CLIMATE..................................................... NORMAL
SPINDLE DRIVE......................................................... A.C. ASYNCHRONOUS
FEED DRIVE............................................................ A.C. SYNCHRONOUS

X AXIS TRAVEL........................................................ 137.7"
Y AXIS TRAVEL........................................................ 78.7"
Z AXIS TRAVEL........................................................ 49.2"
W AXIS TRAVEL........................................................ 31.4 "
SPINDLE DIAMETER..................................................... 5.1"
SPINDLE MAIN MOTOR POWER (S1)........................................ 50 HP
SPINDLE TAPER........................................................ CAT 50 (SK50)
CNC CONTROL SYSTEM................................................... FANUC FS 0i-MF PLUS
LINEAR SCALES........................................................ HEIDENHAIN
CNC ROTARY TABLE..................................................... 62.9" x 70.8" with max., 26,455 lb. load

EQUIPPED WITH:
AIR CONDITIONED ELECTRIC SWITCHBOARD
UL-CERTIFIED EXECUTION
AUTOMATIC SYSTEM OF SLIDE GUIDEWAYS LUBRICATION
HYDRAULIC UNIT
COOLING UNIT FOR THERMAL STABILIZATION OF SPINDLE BEARINGS

OPTIONAL ACCESSORIES:
COOLANT SYSTEM
