KAO MING Model KMR-700DS "NEW" Radial Drill Press

Kao Ming Model KMR-700DS

Features:
• Compact Handles & Push Buttons are simply designed and easy to operate.
• A hydraulic system is used to change the Spindle Speed through 6 Spindle Speed Ranges. Set Spindle Speeds work in conjunction with Automatic Feed capability allowing to set specific feed rates for drilling various materials: Aluminum, Alloy Steel, etc.
• A multiple disc clutch allows for starting and stopping the spindle in order to repeat normal and reverse operations smoothly.
• Specific drilling depth setting capability.

Distance Between Spindle Center and Column Center

Max. Distance......................................................................................... 31 7/8”
Min. Distance.......................................................................................... 11 13/32”

Distance Between Spindle Center and Column Face
Max. Distance......................................................................................... 28”
Min. Distance.......................................................................................... 7 15/32”

Column Diameter.................................................................................... 7 7/8”

Column Height........................................................................................ 77 13/32”

Distance from Spindle Nose to Base Surface
Max. Distance......................................................................................... 41 15/16”
Min. Distance.......................................................................................... 12 19/32”

Max. Height from Spindle Head to Base Bottom.................................85 9/32”

Base Height............................................................................................. 5 3/4”

Base Work Area......................................................................................35 5/32” x 24 13/16”

Base Floor Space................................................................................... 49 7/32” x 25 19/32”

Floor Space............................................................................................. 68 1/8” x 42 1/2”

Spindle Head Longitudinal Travel.......................................................... 20 15/32”

Radial Arm Vertical Travel...................................................................... 21 1/16”

Spindle Travel.......................................................................................... 8 1/4”

Morse Taper in Spindle........................................................................... No. 4
Spindle Speed Range.............................................................................. 6 Steps 88~1500 RPM
Available Feed Rates Per Revolution..................................................... 0.003” Per Rev. ~ 0.0052” Per Rev ~ 0.009" Per Rev..

Main Spindle Motor................................................................................ 2HP
Radial Arm Elevating Motor.................................................................... 1 HP
Machine Weight....................................................................................... 2,843 Lbs.
Machine Dimensions............................................................................... 55“ x 31“ x 77“

Request a detailed price proposal for additional delivery information as well as our terms and conditions.
