New 2025 Clausing CSG818H Reciprocating Surface Grinder – 8” x 18” Table Size, with Manual X, Y, Z Travel
Have one to sell?
ConditionNew
New
Discover the new 2025 Clausing Manual Precision Surface Grinder, 8”x18” table size, with manual X, Y , Z travel, X Maximum travel of 20”, Ball ways between table and saddle, timing belt table drive, 2 Hp Spindle drive motor, 230 or 460 volts, 3 phase.
Machine Type Manual Grinder
Drive Type V3 class motor
Table Size (inch)........ 8 x 18
Maximum Grinding Length (inch) 18.9
Maximum Grinding Width (inch) 8.9
Maximum Distance from table to centerline (inch) 18
Optional Standard Magnetic Chuck Size (inch) 8 x 18
Maximum Table Longitudinal Travel Manual (inch) 20
Maximum Cross Feed Travel Manual (inch).. 9.84
Cross Feed Hand Wheel Revolution Travel (inch) 0.2
Cross Feed Hand Wheel Graduation (inch).. 0.0005
Spindle RPM 3450
Drive Motor Horsepower 2
Grinding Wheel Dimensions (D x W x Bore inch) 8 x ½ or ¾ x 1.25
Machine Weight (lbs.) 2,332
Machine Floor Space (L x W x H inch) 71.3 x 50.6 x 66.1
