Clausing SUP10BVSCNC CNC Bed Mill

Machine Style..........CNC Super Bed Mill
Spindle Speed Control..........Electronic Variable Speed
Number of Controlled Axes..........3 (X, Y, Z-Column)
Manual Quill Scale W-Axis..........Yes (synchronized)
Spindle Motor Horsepower..........7.5
Table Size (inch)..........17.7 x 70.8
Table Load Capacity (lbs.)..........2,500
T-Slot Width (in)..........(.630)
T-Slot Center Distance (inch)..........3.75
Number T-Slots..........3
Table Way Design..........Dovetail
Cross Feed Way Design..........Square
Column Way Design..........Square
X – Longitudinal Travel Manual (inch)..........51.18
Y – Cross Travel Manual (inch)..........23.6
Z – Column Travel Manual (inch)..........27.55
W – Quill Travel (inch)..........5.5
Programmed Feed Rate X,Y (in/min)..........0 – 29.53
Rapid Feed X,Y (in/min)..........472
Programmed Feed Rate Z (in/min)..........0 -29.53
Rapid Feed Z (in/min)..........100
Head Tilt Left or Right..........45°
Variable Spindle Speed (rpm)..........50 – 5000
Variable Spindle Speed Low Range (rpm)..........50 – 590
Variable Spindle Speed High Range (rpm)..........575 – 5000
Spindle Taper..........NMTB 40
Quill Feed (in/rev)..........(.0013/.0028/.0055)
Quill Diameter (inch)..........4.33
Length of Saddle on Bed (inch)..........54
Width Across Bed Ways (inch)..........23
Spindle Nose to Table (inch)..........3.34 – 23
Center of Spindle to Column Ways (inch)..........22.8
Floor to Table Surface (inch)..........35
Voltage Required..........230 or 460 (w/transformer)
Phase..........3
Machine Weight (lbs.)..........8,750
Machine Foot Print (WxDxH) (inch)..........108.3 x 95.9 x 115.4
Shipping Weight (lbs.)..........9,900

Machine Features:
Fanuc Oi Control
C5 double nut X,Y,Z axes 1.26” diameter ballscrew
Linear position feedback X,Y, Z-Column, Manual W-Quill
Powerful 7.5 Hp main spindle drive motor
Manual Dial variable spindle speed with 2 mechanical shift ranges
Hardened and ground spindle with NMTB/NT 40 spindle taper
Hardened and chromed quill with 5.5” travel
CP4 ABEC7 angular contact spindle bearings
Hardened and ground table surface with ground t-slots for reference edges
Hardened and ground dovetail ways X axis, hardened and ground square ways Y and Z axis
“Turcite B” coating on saddle X,Y,Z axes ways
1:2 Ratio timing belt boxes X, Y, Z axes for increased feed torque
High grade castings for superior rigidity and wear resistance
Stainless steel Y, Z axis way covers
Automatic lubrication with alarm
Halogen worklight
Coolant system with pump
A one year warranty backed by Clausing Service Center dedicated to support our customers with parts and service
