New 2025 Clausing SUP30BVSCNC CNC Bed Mill

Table Size..........92” x 30”
Table Size LT-Series..........112” x 30”
Table Load Capacity..........3,960 lbs.
No. of T-slots..........5
T-slot Width..........(.708”)
Table Ways (X Axis)..........Dovetail
Bed Ways (Y Axis)..........Square
Column Ways (Z Axis)..........Square
Longitudinal (X Axis)..........78.7”
Longitudinal (X Axis) LT-Series..........98.4”
Cross (Y Axis)..........33.8”
Cross (Y Axis) LT-Series..........33.8”
Vertical (Z Axis)..........27.9”
Quill Diameter..........4.33”
Spindle Nose to Table Surface..........3.94” to 31.8”
Rapid Transverse Rate X & Y..........787 (in/min)
Rapid Transverse Rate Z..........787 (in/min)
Programmable Feed rate X & Y..........0-196 (in/min)
Programmable feed rate Z..........0-196 (in/min)
feed rate Override (5% increments)..........5% – 150%
Motor..........20
Spindle Speed (Infinitely Variable)..........8000 rpm
No. of Speed Ranges..........1
Spindle Taper..........CAT 40
Spindle Drawbar..........Retention Knob
Length..........220.2”
Width..........122”
Length LT-Series..........240.2”
Width..........122”
Height..........114.2”
Ball Screw Dia. X,Y,Z..........1.96”
Ball Screw Class..........C5
Machine Weight (Approx)..........14,900 lbs.
Machine Weight LT-Series (Approx)..........15,400 lbs.
Shipping Length..........171.3”
Shipping Width..........89.8”
Shipping Height..........100.4”
Shipping Weight..........16,400 lbs.

Machine Features:
10.4” Fanuc Oi Control Panel mounted on swivel arm for operator with touch screen panel for convenience and ease of use
20HP Spindle Motor for strong high torque machining
CAT 40 Spindle 8,000 rpm spindle speed, retention knob drawbar
High Grade Castings Annealed and Stress Relieved provides high rigidity and wear resistance
Harden and Ground Ball Screws C5 double nut on all 3 axes provide high precision movement and reduce heat deformation
X,Y,Z slide ways and table hardened and ground for accuracy
Dovetail and Box Ways provide wear and accuracy over the life of the machine Dovetail X and Y,Z Box
Turcite-B Coating on all 3 axes for wear ability
X/Y/Z Axes 2.4HP Z axis with brake
1:2 Ration Timing Belt Boxes X,Y,Z increase drive torque
Y,Z Steel Way Covers protect slide ways and ball screws from dust and coolant
Coolant System provides better tool life and production rates
Automatic Lube Pump ludes all ways and ball screws for better machine life.
Rear Splash Guards and Coolant Tray are standard to help maintain a clean working environment
Semi-guarding Head and Table Guard promotes a clean and safe working environment and interlocked table guard
Electric Cabinet heat exchanger for better electrical component life
Halogen Work light
Leveling Bolt and Pads
Positioning Accuracy +/- .0004”/FT
Repeatability Accuracy +/- .0002”/FT
Ethernet along with RS232 and USB interface
A one year warranty backed by Clausing Service Center dedicated to support our customers with parts and service
