FEMCO BMC-110R2 "NEW" CNC Table Type Horizontal Boring, Milling & Drilling Machine

FEMCO BMC-110R2 "NEW" CNC Table Type Horizontal Boring, Milling & Drilling Machine

Have one to sell?
(440) 359-2655
leads@wigglesworth.com
ConditionNew
497 available
Have one to sell?

Document (1)

BMC-R-ebrochure.pdf

Overview

Type:
BORING MILLS, HORIZ., TABLE TYPE, N/C & CNC
Manufacturer:
Femco
Model:
BMC-110R2
Stock #:
11270
Status:
For Sale

Description

#50 Taper, 35 HP Geared Head Spindle,
Full B Axis Rotary Table, linear scales on X, Y & Z, chip conveyor,
Fanuc CNC control. Delivery, Installation and Training.......

Spindle Size4.33"109.98 mm
X-Horiz Tvl of Table78.74"2,000 mm
Y-Vert Tvl of Head70.87"1,800.1 mm
Power35 hp26.1 kW
RPM2,500 RPM2,500 RPM
Table-W56.69"1,439.9 mm
Table-L62.99"1,599.9 mm
Spindle Tvl.19.6"497.84 mm
Dimensions78.74” x 70.87” x 64.96”78.74” x 70.87” x 64.96”

Spindle Speed 2,500 RPM (CT-50 Taper – 30/35 HP)
Through Spindle Coolant
60 Tool ATC
Full B-Axis Rotary Table (13,889 Lbs. Load Capacity)
Travel W-Axis: 19.69”
