13" X 20" ROLL-IN SAW VERTICAL BAND SAW

MODEL: JE1320 - JOURNEYMAN

FEATURES:
*ACCURATELY CONTROL BLADE SPEED WITH THE ONBOARD DIGITAL INVERTER DRIVE
*ADJUSTO-BLOK GUIDES FOR 1/4" TO 3/4" BLADE WIDTHS
*OPTIONAL SAW BLADE WELDER, GRINDER, AND SHEAR FOR LONGER SAW BLADE LIFE

SPECIFICATIONS:
FEED SYSTEM.................. N/A
BLADE TRAVEL................. N/A
CUTTING CAPACITY AT 90 DEG... ROUND: 13" RECTANGLE: 20" X 13"
MITER CUT ANGLE RANGE........ 0 - 45 DEGREES
BEVEL CUT ANGLE RANGE........ N/A
CAPACITY UNDER GUIDES........ 13"
THROAT....................... 20"
BLADE SIZE (SHIPS WITH SAW).. 3/4" WIDTH x 12'10" LENGTH 0.35 THICK (BI-METAL)
BLADE SIZE (ACCEPTED WIDTHS). 1/4", 3/8", 1/2", 5/8", AND 3/4"
BLADE SPEEDS................. 70 - 500 SFPM (DIGITAL SPEED CONTROL)
TABLE........................ PRECISION GROUND STEEL TABLE: 24" X 24 1/4"
TABLE HEIGHT................. 37" FROM FLOOR
MOTOR........................ 2 HP 220/440, 60 CYCLE 3 PHASE
SAW DIMENSIONS............... 46" W x 80" H x 30" L
SHIPPING DIMENSIONS.......... 48" W x 86" H x 39" L
SHIPPING WEIGHT.............. 800 LBS

PRICE:
ROLL-IN SAW JE1320 JOURNEYMAN VERTICAL BAND SAW

OPTIONAL EQUIPMENT:
5' ROLLER CONVEYOR
10' ROLLER CONVEYOR
FACTORY INSTALLED WORK LIGHT
MIST COOLANT SYSTEM
WELDER, GRINDER & SHEAR

REPLACEMENT BLADES:
3/4" x 12'10"L x 0.035 (8/12T) - BI-METAL
3/4" x 12'10"L x 0.035 (10t) - CARBON
BLADE TENSION GUIDE

NOTE:
THIS MACHINE IS OFFERED F.O.B. CLEVELAND, OHIO
PRICES SHOWN ARE FOR REPLACEMENT ONLY AND CANNOT BE USED FOR COMPUTING
DEDUCTIONS WHEN MACHINES ARE ORDERED WITHOUT CERTAIN PARTS, NOT FOR ALLOWANCES
ON PARTS RETURNED
PRICES AND SPECIFICTIONS SUBJECT TO CHANGE WITHOUT NOTICE
