12" X 20" ROLL-IN SAW JM1220 JOURNEYMAN ADJUSTABLE TABLE VERTICAL BAND SAW

MODEL: JM1220 - JOURNEYMAN

FEATURES:
*THIS MULTIFACETED JOURNEYMAN TILT TABLE ALLOWS USERS TO EASILY MAKE
CONTOUR, PROFILE, RIP, AND COMPLEX ANGLE CUTS
*QUICKLY MAKE SPECIALTY CUTS WITH THE EASILY ADJUSTABLE TABLE THAT
TILTS UP TO 45 DEGREES
*IMPROVES EFFICIENCY THROUGH A DUAL-SOURCED WEIGHTED/HYDRAULIC TABLE
FEED
*FAST & ACCURATE ALL-PURPOSE SAW, WITH THE BENEFITS OF BOTH A VERTICAL
AND HORIZONTAL SAW

SPECIFICATIONS:
FEED SYSTEM.................. GRAVITY FEED
BLADE TRAVEL................. 11" (TABLE TRAVELS, NOT THE BLADE)
CUTTING CAPACITY AT 90 DEG... ROUND: 12" RECTANGLE: 20" X 12"
MITER CUT ANGLE RANGE........ 0 - 45 DEGREES
BEVEL CUT ANGLE RANGE........ 0 - 45 DEGREES
CAPACITY UNDER GUIDES........ 12"
THROAT....................... 20"
BLADE SIZE (SHIPS WITH SAW).. 3/4" WIDTH x 12'10" LENGTH 0.35 THICK (BI-METAL)
BLADE SIZE (ACCEPTED WIDTHS). 1/4", 3/8", 1/2", 5/8", AND 3/4"
BLADE SPEEDS................. 70 - 500 SFPM (DIGITAL SPEED CONTROL)
TABLE........................ TILTING PRECISION GROUND STEEL TABLE: 24" X 24"
TABLE HEIGHT................. 40" FROM FLOOR
MOTOR........................ 2 HP 220/440, 60 CYCLE 3 PHASE
SAW DIMENSIONS............... 46" W x 80" H x 30" L
SHIPPING DIMENSIONS.......... 48" W x 86" H x 39" L
SHIPPING WEIGHT.............. 1,000 LBS

ROLL-IN SAW JM1220 JOURNEYMAN VERTICAL BAND SAW

OPTIONAL EQUIPMENT:
5' ROLLER CONVEYOR
10' ROLLER CONVEYOR
FACTORY INSTALLED WORK LIGHT
MIST COOLANT SYSTEM
WELDER, GRINDER & SHEAR

REPLACEMENT BLADES:
3/4" x 12'10"L x 0.035 (8/12T) - BI-METAL
3/4" x 12'10"L x 0.035 (10t) - CARBON
BLADE TENSION GUIDE

LEAD TIME: 4-6 WEEKS

NOTE:
THIS MACHINE IS OFFERED F.O.B. CLEVELAND, OHIO
PRICES AND SPECIFICTIONS SUBJECT TO CHANGE WITHOUT NOTICE
