* Fanuc 18-T Control
* 5000 RPM
* 10 HP Spindle
* Coolant System with Chip Conveyor
* 6 ID Tool Holders
* ~50 Collets
* 10 Straight & Right Angle Milling and Drilling Live Tools
Specifications:
Swing.......................................... 21"
Machining Length............................... 13"
Chuck Size..................................... 6"
Bar Capacity................................... 1.625"
Power.......................................... 10 HP
Speed.......................................... 5000 RPM
Turning Diameter............................... 9"
X-axis travel.................................. 5.31″
Z-axis travel with collet...................... 13.9″
Turret positions............................... 12
Approx. Weight................................. 9,000 lbs.
Approx. Lathe Dimensions (l x w x h)........... 84” x 66″ x 68″
Conveyor Dimensions (l x w x h)................ 86” x 24″ x 55"
Equipped With:
* Fanuc 18-T Control
* Coolant System with Chip Conveyor
* 6 ID Tool Holders
* ~50 Collets
* 10 Straight & Right Angle Milling and Drilling Live Tools
