New DAH LIH MCH-500 | Horizontal Machining Centers
Have one to sell?
ConditionNew
New
Horizontal Machining Center
High-precision, highly-efficient machines lead in the coming age.
Greeting the new era with
varied performances.
Column: An assisting pneumatic system is employed in Z axis slideways to reduce friction of column feed by semi-floating way. This can make column movement smooth without "sticking-stiff". This not only increases accuracy, but also reduces the wear of Turcite-B of slideways.
STANDARD ACCESSORIES
Spindle cooling device
Heat exchanger
Automatic pallet changer with manual rotation
Removable-type manual pulse generator
X.Y. Z linear scales
Flood coolant device
Coolant tank
Spindle type chip conveyors
Spindle load meter
Spindle speed meter
Automatic power cut-off device
Call light
Work light
Tool kit
Horizontal Machining Center
High-precision, highly-efficient machines lead in the coming age.
Greeting the new era with
varied performances.
Column: An assisting pneumatic system is employed in Z axis slideways to reduce friction of column feed by semi-floating way. This can make column movement smooth without "sticking-stiff". This not only increases accuracy, but also reduces the wear of Turcite-B of slideways.
STANDARD ACCESSORIES
Spindle cooling device
Heat exchanger
Automatic pallet changer with manual rotation
Removable-type manual pulse generator
X.Y. Z linear scales
Flood coolant device
Coolant tank
Spindle type chip conveyors
Spindle load meter
Spindle speed meter
Automatic power cut-off device
Call light
Work light
Tool kit
Imperial
| X | 750 mm |
| Y | 680 mm |
| Z | 600 mm |
| Power | 18.5 kW |
| RPM | 6,000 RPM |
| # ATC | 60 |
| Taper | NT50 |
| Pallet-W | 500 mm |
| Pallet-L | 500" |
| # Axis | 3 |
| Dimensions | 3,170 x 4,920 mm |
| Weight | 15000 (KGS) |
