New Acer 1454-II "Rigid Head" CNC Bed Mill w/12-Tool ATC & FANUC 0i-MF CNC Control
Have one to sell?
ConditionNew
New
Discover precision engineering with the new Acer 1454-II Bed Mill, featuring a 12-tool ATC and FANUC 0i-MF CNC Control. With a 7.5 HP spindle motor and advanced control software, this machine promises high-speed operations and optimal performance.
General Information:
Table:
• Table Size:.......... 14" x 54" (356 x 1372mm)
• T-Slots:.......... 3 x 5/8" (16mm)
• Table Load:.......... 1960 lbs (891kgs)
Travel:
• X Axis Max./Rapid Feed:.......... 40" (1016mm)/200ipm
• Y Axis Max./Rapid Feed:.......... 22.44"(570mm)/200ipm
• Z Axis Max./Rapid Feed:.......... 26.77"(680mm)/200ipm
• Max Spindle Nose to Table:.......... 1"(25.4mm)~27.75" (705mm)
• Spindle Center to Column Face:.......... 21.3" (540mm)
Spindle:
• Quill Diameter:.......... 4.72" (120mm)
• Quill Travel.......... -
• Spindle Taper:.......... CAT#40 (BT#40, NMTB#40 Opt.)
• Spindle Speed Hi/Low RPM:.......... 0~6000
Motor:
• Spindle HP:.......... 7.5
• X Axis Servo Motor:.......... DC 31.3 in-lb or AC 1.5KW
• Y Axis Servo Motor:.......... DC 31.3 in-lb or AC 1.5 KW
• Z Axis Servo Motor:.......... DC 31.3 in-lb or AC 2.2 KW
• Coolant Pump HP (Opt.):.......... 1/8
• Lubrication Pump Watts:.......... 80
ATC Tool Dimension & Capacity:
• Tool Total Length:.......... 12" (300mm)
• Tool Maximum Width:.......... 2.95" (75mm)
• Tool Total Weight:.......... 15 lbs (8kgs)
• Total Tool Number:.......... 8, 10, or 12
Power & Air Requirements:
• Control..........110V/1P/20A or 230V/3P/50A
• Machine.......... 230V(460V)/3P/14A(7A) or single phase 230V
• Pneumatic Pressure (Air Req.):.......... 85psi (6kg/cm²) min.
Dimensions:
• Max Height:.......... 104.7" (2660mm)
• Height from Table Top to Bottom of Bed:.......... 31.5" (800mm)
• Width of Machine Including Table:.......... 94.49" (2400mm)
• Overall Length with Electrical Door Closed:.......... 84.65" (2150mm)
• Overall Length with Electrical Door Open:.......... 109.06" (2770mm)
• Overall Width with Full Table Traverse:.......... 141.73"(3600mm)
• Footprint of Machine inches:.......... 100" x 74" x110"
• Footprint of Machine metric:.......... 2540 x 1880 x 2794mm
• Max. Machine Operation Space:.......... 135.8" x 109.1" x 104.7" (345x277 x 266cm)
• Packing Dimension Approx (X x Y x Z w/balancing block):........... 90.55" x 90.55" x 96.46" (30 x 230 x 245cm)
• Net Weight Approx.:.......... 7612 lbs (3460 kgs)
• Gross Weight Approx.:.......... 7880 lbs (3582 kgs)
Maximum Working Capacity in Mild Steel:
• Drilling Max Capacity:.......... Ф1-1/2" (38mm)
• Milling Max Capacity:.......... 5mm x Ф100mm
• Boring Capacity:.......... Ф6.3" (160mm)
• Tapping Max Capacity:.......... 1.18" (30mm)
Optional Accessories:
• Angle Lock Milling Vise
• 52pcs Clamping Kit
• Manual Horizontal/Vertical Rotary Table
• T-Slot Cover
• Telescopic Stainless Cover
• Spindle Guard
• Hydraulic Machine Vise
• Air Power Drawbar
• CAT or BT#40 Tool Holder Set
• Coolant System
• Semi-Universal Dividing Head
• CNC Power Vise
• Column Side Guard and Chip Pan
• Chip Pan
• Table Guard
• Riser Block for 1454 Model
• 4th Axis Rotary Table
• Tailstock
• Table Top Guard
• Halogen or LED light
“Fanuc” CNC Optional Accessories:
• Upgrade to 2GB CF
• Ethernet
• Engraving
• Programming Spindle R.P.M.
• Manual Pulse Generator
• Remote Start / Stop Switch
• Home Position Switch for Home & Fixture Offset
• One Day On-Site Program Training
Discover precision engineering with the new Acer 1454-II Bed Mill, featuring a 12-tool ATC and FANUC 0i-MF CNC Control. With a 7.5 HP spindle motor and advanced control software, this machine promises high-speed operations and optimal performance.
T.R. Wigglesworth Machinery Co. has proudly represented the ACER group (Klim industrial) for more than Twenty years now, along with the factory in Taiwan.
Acer pursues excellence in (4) four main areas: Quality, Value, Service, Availability. Acer Machines are superior in quality, fit and finish. The proposals we offer are highly competitive. ACER offers product support in the field, and on the phone.
Allow T.R. Wigglesworth Machinery Co to propose the right ACER product to meet your requirements today.
