Discover the New Kao Ming KMC-418HIS Gantry Machining Center, designed for maximum ridgigity and precision.
Features include: a 10,000 RPM direct drive spindle, 30 tool ATC, and advanced linear guideways. Ideal for heavy-duty tasks and extreme rigidity.
FEATURES:
DOUBLE COLUMN DESIGN PROVIDES STABILITY WHILE HEAVY DUTY CUTTING
THREE AXES HIGH PRECISION, PRELOADED ROLLER LINEAR GUIDEWAYS
Y-AXIS STEP DESIGN OF THE DUAL GUIDEWAYS PROVIDES EXTREME RIGIDITY
ALL BALL SCREWS ARE PRELOADED FOR EXCELLENT ACCURACY
AUTOMATIC LUBRICATION SYSTEM
RIGID 10,000 RPM DIRECT DRIVE SPINDLE (30/35 HP)
FULLY ENCLOSED SPLASH GUARD
30 TOOL MAGAZINE ATC... 40,50,60 OR 90* MAGAZINE OPTIONS AVAILABLE
MAJOR COMPONENTS ARE HEAVILY RIBBED REINFORCED FOR OUTSTANDING STABILITY
MEEHANITE CAST IRON USED FOR ALL MAJOR MACHINE COMPONENTS
REFRIGERATED SPINDLE CHILLER
SPECIFICATIONS:
DISTANCE BETWEEN COLUMNS......................... 70.86"
TABLE:
TABLE SIZE OVERALL............................... 157.4" X 64.96"
T SLOTS (NUMBER X WIDTH X PITCH)................. 9 X 0.86" X 6.69"
TABLE LOAD....................................... 26,400 LBS
X,Y,Z AXIS TRAVEL................................ 166.53" X 66.92" X 33.46"
SPINDLE NOSE TO TABLE............................ 5.90"-39.37"
SPINDLE:
SPINDLE TAPER.................................... CT-50
PULL STUD........................................ CT-50
SPINDLE SPEEDS................................... 10,000 RPM
HORSEPOWER....................................... 30/35 HP
TRANSMISSION..................................... DIRECT DRIVE
FEED RATES:
RAPID TRAVERSE X,Y,Z AXIS........................ 787/944/590 IPM
FEED RATE X,Y,Z AXIS............................. 0.1-393 IPM
AUTOMATIC TOOL CHANGER:
MAGAZINE CAPACITY................................ 30 TOOL ARM 40,50,60, OR 90 OPTIONAL
MAXIMUM TOOL LENGTH.............................. 13.77"
MAXIMUM TOOL DIAMETER............................ 5.11"
WITHOUT ADJACENT TOOL............................ 7.87"
MAXIMUM TOOL WEIGHT.............................. 44 LBS
COOLANT SYSTEM:
COOLANT TANK SIZE................................ 264 GALLONS WITH CTS*
MACHINE SIZE:
FLOOR AREA (L X W X H)........................... 399" X 192" 174"
NET WEIGHT....................................... 60,500 LBS
AIR REQUIRED..................................... 85 PSI
POWER REQUIRED................................... 220 VOLT AC, 3 PHASE, 60KVA
STANDARD ACCESSORIES:
FANUC CONTROL AUTO LUBE SYSTEM
ARM TYPE ATC 30 TOOLS SPINDLE CHILLER
RIGID TAPPING SPINDLE COOLANT SYSTEM
SCREW TYPE CHIP CONVEYOR SPINDLE LOAD METER
FULL ENCLOSURE SPINDLE RPM METER
AIR BLLAST WORK LIGHT
FULLY ENCLOSED SPLASHGUARD ALARM LIGHT
OPERATIONS, CONTROL AND MAINTENANCE MANUALS SAFETY DOOR INTERLOCK
SPINDLE AIR BLOW TOOLBOX
LEVELING BOLTS, PADS & NUTS TELESCOPIC WAY COVERS
