Clausing SUP16BVSCNC CNC Bed Mill
Have one to sell?
ConditionNew
New
Discover precision and power with the new Clausing SUP16BVSCNC CNC Bed Mill. Featuring a 19.68" x 86.6" table, 62.99" longitudinal travel, and a robust 7.5 hp motor, it offers 3-axis control, high-grade castings, and advanced Fanuc Oi Control.
Machine Style..........CNC Super Bed Mill
Spindle Speed Control..........Electronic Variable Speed
Number of Controlled Axes..........3 (X, Y, Z-Column)
Manual Quill Scale W-Axis..........Yes (synchronized)
Spindle Motor Horsepower..........7.5
Table Size (inch)..........19.68 x 86.6
Table Load Capacity (lbs.)..........2,500
T-Slot Width (in)..........(.630)
T-Slot Center Distance (inch)..........3.75
Number T-Slots..........3
Table Way Design..........Dovetail
Cross Feed Way Design..........Square
Column Way Design..........Square
X – Longitudinal Travel Manual (inch)..........62.99
Y – Cross Travel Manual (inch)..........27.55
Z – Column Travel Manual (inch)..........27.55
W – Quill Travel (inch)..........5.5
Programmed Feed Rate X,Y (in/min)..........0 – 29.53
Rapid Feed X,Y (in/min)..........472
Programmed Feed Rate Z (in/min)..........0 -29.53
Rapid Feed Z (in/min)..........100
Head Tilt Left or Right..........45°
Variable Spindle Speed (rpm)..........50 – 5000
Variable Spindle Speed Low Range (rpm)..........50 – 590
Variable Spindle Speed High Range (rpm)..........575 – 5000
Spindle Taper..........NMTB 40
Quill Feed (in/rev)..........(.0013/.0028/.0055)
Quill Diameter (inch)..........4.33
Length of Saddle on Bed (inch)..........54
Width Across Bed Ways (inch)..........23
Spindle Nose to Table (inch)..........3.34 – 23
Center of Spindle to Column Ways (inch)..........26.37
Floor to Table Surface (inch)..........35
Voltage Required..........230 or 460 (w/transformer)
Phase..........3
Machine Weight (lbs.)..........9,900
Machine Foot Print (WxDxH) (inch)..........126.8 x 99.6 x 114.6
Shipping Weight (lbs.)..........10,900
Machine Features:
Fanuc Oi Control
C5 double nut X,Y,Z axes 1.26” diameter ballscrew
Linear position feedback X,Y, Z-Column, Manual W-Quill
Powerful 7.5 Hp main spindle drive motor
Manual Dial variable spindle speed with 2 mechanical shift ranges
Hardened and ground spindle with NMTB/NT 40 spindle taper
Hardened and chromed quill with 5.5” travel
CP4 ABEC7 angular contact spindle bearings
Hardened and ground table surface with ground t-slots for reference edges
Hardened and ground dovetail ways X axis, hardened and ground square ways Y and Z axis
“ Turcite B” coating on saddle X,Y,Z axes ways
1:2 Ratio timing belt boxes X, Y, Z axes for increased feed torque
High grade castings for superior rigidity and wear resistance
Stainless steel Y, Z axis way covers
Automatic lubrication with alarm
Halogen worklight
Coolant system with pump
A one year warranty backed by Clausing Service Center dedicated to support our customers with parts and service
Discover precision and power with the new Clausing SUP16BVSCNC CNC Bed Mill. Featuring a 19.68" x 86.6" table, 62.99" longitudinal travel, and a robust 7.5 hp motor, it offers 3-axis control, high-grade castings, and advanced Fanuc Oi Control.
For over 113 years, Clausing has been a leader in the Metalworking industry with rugged dependable Machine Tools. Today, Clausing markets and manufactures the best Machine Tools the world has to offer. Every product is backed by our independently operated Clausing Service Center. The service center has over 80,000 parts and 95% of all orders are shipped within 24 hours. Highly qualified technicians are available to provide phone and on-site support.
CNC Bed Mills
A CNC bed mill is designed for large workpieces and heavy-duty applications. These machines feature large, flatbeds for stabilizing workpieces, and they can move work tools vertically or horizontally to remove material. While these milling machines are commonly used for machining of large plates, they have many applications in a wide range of industries such as aerospace and defense.
At Clausing, we've developed CNC bed mills with versatility and heavy-duty construction to work for your unique application.
Imperial
| Table-W | 19.68" |
| Table-L | 86.6" |
| # Axis | 3 |
| Travel-Long | 62.99" |
| Travel-Cross | 27.55" |
| Power | 7.5 hp |
| RPM | 5,000 RPM |
| Taper | NMTB 40 |
| Control | CNC (Fanuc Oi Control) |
| Dimensions | 126.8" x 99.6" x 114.6" |
| Weight | 9,900Lbs |
Machine Style..........CNC Super Bed Mill
Spindle Speed Control..........Electronic Variable Speed
Number of Controlled Axes..........3 (X, Y, Z-Column)
Manual Quill Scale W-Axis..........Yes (synchronized)
Spindle Motor Horsepower..........7.5
Table Size (inch)..........19.68 x 86.6
Table Load Capacity (lbs.)..........2,500
T-Slot Width (in)..........(.630)
T-Slot Center Distance (inch)..........3.75
Number T-Slots..........3
Table Way Design..........Dovetail
Cross Feed Way Design..........Square
Column Way Design..........Square
X – Longitudinal Travel Manual (inch)..........62.99
Y – Cross Travel Manual (inch)..........27.55
Z – Column Travel Manual (inch)..........27.55
W – Quill Travel (inch)..........5.5
Programmed Feed Rate X,Y (in/min)..........0 – 29.53
Rapid Feed X,Y (in/min)..........472
Programmed Feed Rate Z (in/min)..........0 -29.53
Rapid Feed Z (in/min)..........100
Head Tilt Left or Right..........45°
Variable Spindle Speed (rpm)..........50 – 5000
Variable Spindle Speed Low Range (rpm)..........50 – 590
Variable Spindle Speed High Range (rpm)..........575 – 5000
Spindle Taper..........NMTB 40
Quill Feed (in/rev)..........(.0013/.0028/.0055)
Quill Diameter (inch)..........4.33
Length of Saddle on Bed (inch)..........54
Width Across Bed Ways (inch)..........23
Spindle Nose to Table (inch)..........3.34 – 23
Center of Spindle to Column Ways (inch)..........26.37
Floor to Table Surface (inch)..........35
Voltage Required..........230 or 460 (w/transformer)
Phase..........3
Machine Weight (lbs.)..........9,900
Machine Foot Print (WxDxH) (inch)..........126.8 x 99.6 x 114.6
Shipping Weight (lbs.)..........10,900
Machine Features:
Fanuc Oi Control
C5 double nut X,Y,Z axes 1.26” diameter ballscrew
Linear position feedback X,Y, Z-Column, Manual W-Quill
Powerful 7.5 Hp main spindle drive motor
Manual Dial variable spindle speed with 2 mechanical shift ranges
Hardened and ground spindle with NMTB/NT 40 spindle taper
Hardened and chromed quill with 5.5” travel
CP4 ABEC7 angular contact spindle bearings
Hardened and ground table surface with ground t-slots for reference edges
Hardened and ground dovetail ways X axis, hardened and ground square ways Y and Z axis
“ Turcite B” coating on saddle X,Y,Z axes ways
1:2 Ratio timing belt boxes X, Y, Z axes for increased feed torque
High grade castings for superior rigidity and wear resistance
Stainless steel Y, Z axis way covers
Automatic lubrication with alarm
Halogen worklight
Coolant system with pump
A one year warranty backed by Clausing Service Center dedicated to support our customers with parts and service
