Clausing SUP24BVSCNCFG CNC Bed Mill
Have one to sell?
ConditionNew
New
Introducing the Clausing SUP24BVSCNCFG Bed Mill. This new CNC machine boasts a 24" x 72.99" table, 8,000 RPM CAT 40 spindle, and 15/20 HP motor. Experience precise 3-axis control with Fagor 8058 control panel and enjoy superior performance and reliability.
Table Size..........72.99” x 24”
Table Load Capacity..........3,300 lbs.
No. of T-slots..........5
T-slot Width..........(.708”)
Table Ways (X Axis)..........Dovetail
Bed Ways (Y Axis)..........Square
Column Ways (Z Axis)..........Square
Longitudinal (X Axis)..........60”
Cross (Y Axis)..........28.3”
Vertical (Z Axis)..........26.7”
Quill Diameter..........4.33”
Spindle Nose to Table Surface..........3.94” to 31.8”
Rapid Transverse Rate X & Y..........787 (in/min)
Rapid Transverse Rate Z..........787 (in/min)
Programmable Feed rate X & Y..........0-196 (in/min)
Programmable feed rate Z..........0-196 (in/min)
feed rate Override (5% increments)..........5% – 150%
Motor..........15/20 Hp
Spindle Speed (Infinitely Variable)..........8000 rpm
No. of Speed Ranges..........1
Spindle Taper..........CAT 40
Spindle Drawbar..........Retention Knob
Length..........151.6”
Width..........88.6”
Height..........100.4”
Ball Screw Dia. X,Y,Z..........1.57”
Ball Screw Class..........C5
Machine Weight (Approx)..........13,200 lbs.
Shipping Length..........129”
Shipping Width..........90”
Shipping Height..........110”
Shipping Weight..........14,400 lbs.
Machine Features:
10.4” Fagor 8058 Control Panel mounted on swivel arm for operator with touch screen panel for convenience and ease of use
15/20HP Spindle Motor for strong high torque machining
CAT 40 Spindle 8,000 rpm spindle speed, retention knob drawbar
High Grade Castings Annealed and Stress Relieved provides high rigidity and wear resistance
Harden and Ground Ball Screws C5 double nut on all 3 axes provide high precision movement and reduce heat deformation
X, Y, Z slide ways and table hardened and ground for accuracy
Dovetail and Box Ways provide wear and accuracy over the life of the machine Dovetail X and Y, Z Box
Turcite-B Coating on all 3 axes for wear ability
X/Y/Z Axes 2.4HP Z axis with brake
1:2 Ration Timing Belt Boxes X,Y,Z increase drive torque
Y,Z Steel Way Covers protect slide ways and ball screws from dust and coolant
Coolant System provides better tool life and production rates
Automatic Lube Pump ludes all ways and ball screws for better machine life.
Rear Splash Guards and Coolant Tray are standard to help maintain a clean working environment
Semi-guarding Head and Table Guard promotes a clean and safe working environment and interlocked table guard
Electric Cabinet heat exchanger for better electrical component life
Halogen Work light
Leveling Bolt and Pads
Positioning Accuracy +/- .0004”/FT
Repeatability Accuracy +/- .0002”/FT
Ethernet along with RS232 and USB interface
Introducing the Clausing SUP24BVSCNCFG Bed Mill. This new CNC machine boasts a 24" x 72.99" table, 8,000 RPM CAT 40 spindle, and 15/20 HP motor. Experience precise 3-axis control with Fagor 8058 control panel and enjoy superior performance and reliability.
For over 113 years, Clausing has been a leader in the Metalworking industry with rugged dependable Machine Tools. Today, Clausing markets and manufactures the best Machine Tools the world has to offer. Every product is backed by our independently operated Clausing Service Center. The service center has over 80,000 parts and 95% of all orders are shipped within 24 hours. Highly qualified technicians are available to provide phone and on-site support.
CNC Bed Mills
A CNC bed mill is designed for large workpieces and heavy-duty applications. These machines feature large, flatbeds for stabilizing workpieces, and they can move work tools vertically or horizontally to remove material. While these milling machines are commonly used for machining of large plates, they have many applications in a wide range of industries such as aerospace and defense.
At Clausing, we've developed CNC bed mills with versatility and heavy-duty construction to work for your unique application.
Imperial
| Table-W | 24" |
| Table-L | 72.99" |
| # Axis | 3 |
| Travel-Long | 60" |
| Travel-Cross | 28.3" |
| Power | 20 hp |
| RPM | 8,000 RPM |
| Taper | CAT 40 |
| Control | CNC (10.4” Fagor 8058 Control Panel) |
| Dimensions | 151.6" x 88.6" x 100.4" |
| Weight | 13,200Lbs |
Table Size..........72.99” x 24”
Table Load Capacity..........3,300 lbs.
No. of T-slots..........5
T-slot Width..........(.708”)
Table Ways (X Axis)..........Dovetail
Bed Ways (Y Axis)..........Square
Column Ways (Z Axis)..........Square
Longitudinal (X Axis)..........60”
Cross (Y Axis)..........28.3”
Vertical (Z Axis)..........26.7”
Quill Diameter..........4.33”
Spindle Nose to Table Surface..........3.94” to 31.8”
Rapid Transverse Rate X & Y..........787 (in/min)
Rapid Transverse Rate Z..........787 (in/min)
Programmable Feed rate X & Y..........0-196 (in/min)
Programmable feed rate Z..........0-196 (in/min)
feed rate Override (5% increments)..........5% – 150%
Motor..........15/20 Hp
Spindle Speed (Infinitely Variable)..........8000 rpm
No. of Speed Ranges..........1
Spindle Taper..........CAT 40
Spindle Drawbar..........Retention Knob
Length..........151.6”
Width..........88.6”
Height..........100.4”
Ball Screw Dia. X,Y,Z..........1.57”
Ball Screw Class..........C5
Machine Weight (Approx)..........13,200 lbs.
Shipping Length..........129”
Shipping Width..........90”
Shipping Height..........110”
Shipping Weight..........14,400 lbs.
Machine Features:
10.4” Fagor 8058 Control Panel mounted on swivel arm for operator with touch screen panel for convenience and ease of use
15/20HP Spindle Motor for strong high torque machining
CAT 40 Spindle 8,000 rpm spindle speed, retention knob drawbar
High Grade Castings Annealed and Stress Relieved provides high rigidity and wear resistance
Harden and Ground Ball Screws C5 double nut on all 3 axes provide high precision movement and reduce heat deformation
X, Y, Z slide ways and table hardened and ground for accuracy
Dovetail and Box Ways provide wear and accuracy over the life of the machine Dovetail X and Y, Z Box
Turcite-B Coating on all 3 axes for wear ability
X/Y/Z Axes 2.4HP Z axis with brake
1:2 Ration Timing Belt Boxes X,Y,Z increase drive torque
Y,Z Steel Way Covers protect slide ways and ball screws from dust and coolant
Coolant System provides better tool life and production rates
Automatic Lube Pump ludes all ways and ball screws for better machine life.
Rear Splash Guards and Coolant Tray are standard to help maintain a clean working environment
Semi-guarding Head and Table Guard promotes a clean and safe working environment and interlocked table guard
Electric Cabinet heat exchanger for better electrical component life
Halogen Work light
Leveling Bolt and Pads
Positioning Accuracy +/- .0004”/FT
Repeatability Accuracy +/- .0002”/FT
Ethernet along with RS232 and USB interface
