New 2025 Clausing C1540FJ – Geared Head Lathe with 15.25” Swing over Bed, Gap Bed Engine Lathe w/ Foot brake
Have one to sell?
ConditionNew
1 available
New
15.25” Swing over bed, Geared Head Gap Bed Engine Lathe, 7.5 Hp Spindle motor, 40” between centers, 9.5” Swing over the cross slide, 25 to 2000 RPM, 16 Speed, 2.125” Spindle Bore, D1-6 camlock spindle nose, 2.312” Tailstock quill diameter with 4 morse taper bore, Inch/Metric threading with various pitch settings, 230/460 Volts, 3 Phase
Machine Style Engine Lathe
Spindle Speed Control Geared Head
Spindle (Hp) 7.5
Swing Over Bed (inch) 15.25
Swing Over Cross slide (inch) 9.5
Swing in Gap (inch) 24
Distance Between Centers (inch) 40
Bed Width (inch) 11
Spindle Bore (inch) 2.125
Spindle Nose (camlock) D1-6
Spindle Nose Taper 6 MT
Number of Spindle Speeds 16
Spindle Speed RPM Range 25 – 2000
Cross Slide Travel (inch) 9
Width of Cross Slide (inch) 6.47
Top Slide Travel (compound) (inch) 4.75
Tailstock Quill Diameter (inch) 2.312
Tailstock Quill Travel (inch) 6.125
Tailstock Quill Taper 4 MT
Longitudinal Feed Range (in/rev) 0.0015 – 0.04
Cross Feed Range (in/rev) 0.0008 – 0.02
Number of Inch Pitches 45
Range of Inch Pitches 2 – 72
Number of Metric Pitches 39
Range of Metric Pitches 0.2 – 14
Number of Diametral Pitches 21
Range of Diametral Pitches 8 – 44
Number of Module Pitches 18
Range of Module Pitches 0.3 – 3.5
Coolant System Yes
Voltage Required 230/460
Phase 3
Machine Foot Print (LxWxH) (inch) 87 x 40 x 50
Machine Weight (lbs.) 2,530
