New 2025 16″ x 32″ Clausing CSG1632ASDIII Automatic Precision Surface Grinder with Microprocessor

Machine Style.......................... Automatic – Hydraulic
Drive Type............................. Direct Coupled
Table Size (in)........................ 16 x 32
Longitudinal Maximum Travel Hyd (in)... 35
Longitudinal Maximum Travel Manual (in) 36.61
Table Speed Infinitely Variable (in/min)196 – 984
Maximum Cross Auto Traverse Travel (in) 17
Maximum Cross Travel Manual (in)....... 18
Auto Traverse Increment (in)........... 0.04 – 1
Crossfeed Handwheel Revolution (in).... 0.2
Crossfeed Handwheel Graduation (in).... 0.0005
Vertical Automatic infeed (in)......... 0.00005 -0.0025
Step Feed Jog (in)..................... 0.00004
Optional Standard Magnetic Chuck Size (inch) 16 x 32
Grinding Spindle Speed................. 1750 rpm
Standard Grinding Wheel Diameter (in).. 14
Standard Grinding Wheel Width (in)..... 2
Standard Grinding Wheel Bore (in)...... 5
Spindle Motor Horsepower............... 7.5
Hydraulic Motor Horsepower............. 3
Crossfeed Motor Horsepower............. 1
Elevating Motor Horsepower............. 1/4
Coolant System Optional
Machine Weight (lbs.).................. 7,496
Machine Floor Space (L x W x H inch)... 130 x 87 x 81

Machine Features:
• Delta PLC with 7.2” color touch screen equipped with
conversational program language
• Pre-settable hydraulic longitudinal table speed control
allows operator to pre-set speed rate, allowing for same
speed each time you engage the hydraulic feed. Dual throttle
valve for 25mm to 25M speeds
• DC Motorized cross feed with ballscrew
• Programmable up/down head positioning
• Built-in proximity switch for easy operation
• Wheel extraction screw and nut
• Balancing stand with arbor
• Leveling screws with blocks
• Grinding wheel
• Wheel flange
• Auto lubrication system
• Table mounted diamond dresser with diamond
• Micro Down Feed
• Chuck Controller w/De-Mag
• Splash Guard
• 1 year limited warranty
