Elevate your precision grinding with the 2025 Clausing CSG2040ASDIII, featuring a 20" x 40" table, 7.5 HP power, and a digital controller. Automatic hydraulic style ensures efficiency with speeds up to 984 in/min. Compact design fits 164 x 86 x 82.7
Machine Style.......... Automatic – Hydraulic
Drive Type.......... Direct Coupled
Table Size (in).......... 20 x 40
Longitudinal Maximum Travel Hyd (in).......... 41.73
Longitudinal Maximum Travel Manual (in).......... 43.31
Table Speed Infinitely Variable (in/min)..........196 – 984
Maximum Cross Auto Traverse Travel (in).......... 20
Maximum Cross Travel Manual (in).......... 20.47
Auto Traverse Increment (in).......... 0.04 – 1
Crossfeed Handwheel Revolution (in).......... 0.2
Crossfeed Handwheel Graduation (in).......... 0.0005
Vertical Automatic infeed (in).......... 0.00005 - 0.0025
Step Feed Jog (in)..........0.00004
Optional Standard Magnetic Chuck Size (inch) 19.68" x 39.37"
Grinding Spindle Speed.......... 1750 rpm
Standard Grinding Wheel Diameter (in)..........14
Standard Grinding Wheel Width (in)..........2
Standard Grinding Wheel Bore (in)
Spindle Motor Horsepower.......... 7.5
Hydraulic Motor Horsepower.......... 3
Crossfeed Motor Horsepower.......... 1
Elevating Motor Horsepower.......... 1/4
Coolant System Optional
Machine Weight (lbs.).......... 10,582
Machine Floor Space (L x W x H inch).......... 177 x 87 x 83
Machine Features:
• Delta PLC with 7.2” color touch screen equipped with
conversational program language
• Pre-settable hydraulic longitudinal table speed control
allows operator to pre-set speed rate, allowing for same
speed each time you engage the hydraulic feed. Dual throttle
valve for 25mm to 25M speeds
• DC Motorized cross feed with ballscrew
• Programmable up/down head positioning
• Built-in proximity switch for easy operation
• Wheel extraction screw and nut
• Balancing stand with arbor
• Leveling screws with blocks
• Grinding wheel
• Wheel flange
• Auto lubrication system
• Table mounted diamond dresser with diamond
• Micro Down Feed
• Chuck Controller w/De-Mag
• Splash Guard
• 1 year limited warranty
