New 2025 Clausing 3VHS Horizontal - Vertical Combo Mill
Have one to sell?
ConditionNew
New
Introducing the new 2025 Clausing 3VHS Horizontal-Vertical Milling machine. Features include a 5 hp motor, 11.81"x50" table, variable spindle speeds, and an easy-to-use operator panel. High-quality casting and durable design ensure precision and reliability.
Machine Style..........Horizontal-Vertical Combo
Table Area (in)..........11.81″ x 50″
Total Load Capacity (lbs.)..........950
No. of T-slots..........3
Distance Between T-Slots (in)..........3.14
T-slot Size (in)..........0.629
X Manual Longitude (in)..........36.6
Y Manual Cross (in)..........15.7
Z Manual Knee (in)..........17.7
X Automatic Longitude (in)..........36.2
Y Automatic Cross (in)..........14.9
Z Automatic Knee (in)..........17.7
Longitudinal in/min..........0.7-12.5 (6 steps)
Longitudinal Rapid in/min..........41
Cross Feed in/min..........2-87
Vertical Rapid Traverse (knee) in/min..........14
Spindle taper (Vertical)..........NMTB 40
Speed Steps (Vertical)..........Variable
Spindle Speeds RPM (Vertical)..........75-3166
Swiveling Angle Right and Left (Vertical)..........45°
Quill Travel (Vertical) (in)..........5.5
Quill Feeds in/rev (Vertical)..........0.0013/0.0027/0.0055
Spindle Nose to Table (Vertical) (in)..........3.74-21.4
Spindle Center to Column (Vertical) (in)..........7.48-27.16
Cross Travel Ram (Vertical) (in)..........19.68
Spindle Taper (Horizontal) (in)..........NMTB 40
Speed Steps (Horizontal)..........9
Spindle Speeds RPM (Horizontal)..........60-1440
Spindle to Bottom of Ram (Horizontal) (in)..........6.88
Spindle Center to Table (Horizontal) (in)..........0-17.7
Vertical Spindle Hp..........5
Horizontal Spindle Hp..........5
Table Feed Longitudinal Hp..........3/4
Table Feed Cross Hp..........1/2
Table Rapid Vertical Hp..........1/2
Feed Motor Hp..........1/8
Machine Dimensions (LxWxH)..........68.5 x 63.6 x 79
Weight..........5,390
Machine Features:
X Axis (left/right) and Y Axis (in/out) gearbox is controlled at the operator friendly control panel
Mechanical rapid traverse on X, Y & Z axis
Pendant operator panel for ease of operation.
High quality meehanite casting for superior rigidity and wear resistance
All gears and shafts are hardened and ground
Large 50” x 11.8” (1270 x 300mm) angling table with 3 T-slots
All slide ways and table are hardened and ground
Turcite coated X,Y axis for wear resistance
Clamps on all square slide ways
Horizontal manual drawbars
Automatic coolant system and coolant pump
Halogen worklight
Tool box and service tools
CE Electrics for reliability
A one year warranty backed by Clausing Service Center dedicated to support our customers with parts and service
Introducing the new 2025 Clausing 3VHS Horizontal-Vertical Milling machine. Features include a 5 hp motor, 11.81"x50" table, variable spindle speeds, and an easy-to-use operator panel. High-quality casting and durable design ensure precision and reliability.
T.R. Wigglesworth Machinery Company has proudly represented Clausing for over 40 years.
For over 113 years, Clausing has been a leader in the Metalworking industry with rugged dependable Machine Tools. Today, Clausing markets and manufactures the best Machine Tools the world has to offer. Every product is backed by our independently operated Clausing Service Center. The service center has over 80,000 parts and 95% of all orders are shipped within 24 hours. Highly qualified technicians are available to provide phone and on-site support.
Clausing Horizontal Vertical Combo Mills are heavy-duty, reliable, extremely accurate and very versatile machines. These heavy-duty cast iron mills can be used for one-off pieces as well as small to medium size production runs, making them ideal for maintenance tool rooms, job shops or tool and die shops. A wide range of step spindle speeds combined with infinitely variable feed rates makes cutting ferrous and non-ferrous metals highly efficient.
Clausing Horizontal Vertical Combo Mills are designed and built for accuracy featuring hardened and ground alloy steel main spindle mounted on highly accurate bearings. Extra heavy-duty saddle traveling on hardened ground box ways capable of handling table loads up to 950 lbs., large hardened and ground table with 3 T-slots and much more.
Imperial
| Table Size-W | 11.81" |
| Table Size-L | 50" |
| Power | 5 hp |
| Dimensions | 68.5" x 63.6" x 79" |
| Weight | 5390Lbs |
Machine Style..........Horizontal-Vertical Combo
Table Area (in)..........11.81″ x 50″
Total Load Capacity (lbs.)..........950
No. of T-slots..........3
Distance Between T-Slots (in)..........3.14
T-slot Size (in)..........0.629
X Manual Longitude (in)..........36.6
Y Manual Cross (in)..........15.7
Z Manual Knee (in)..........17.7
X Automatic Longitude (in)..........36.2
Y Automatic Cross (in)..........14.9
Z Automatic Knee (in)..........17.7
Longitudinal in/min..........0.7-12.5 (6 steps)
Longitudinal Rapid in/min..........41
Cross Feed in/min..........2-87
Vertical Rapid Traverse (knee) in/min..........14
Spindle taper (Vertical)..........NMTB 40
Speed Steps (Vertical)..........Variable
Spindle Speeds RPM (Vertical)..........75-3166
Swiveling Angle Right and Left (Vertical)..........45°
Quill Travel (Vertical) (in)..........5.5
Quill Feeds in/rev (Vertical)..........0.0013/0.0027/0.0055
Spindle Nose to Table (Vertical) (in)..........3.74-21.4
Spindle Center to Column (Vertical) (in)..........7.48-27.16
Cross Travel Ram (Vertical) (in)..........19.68
Spindle Taper (Horizontal) (in)..........NMTB 40
Speed Steps (Horizontal)..........9
Spindle Speeds RPM (Horizontal)..........60-1440
Spindle to Bottom of Ram (Horizontal) (in)..........6.88
Spindle Center to Table (Horizontal) (in)..........0-17.7
Vertical Spindle Hp..........5
Horizontal Spindle Hp..........5
Table Feed Longitudinal Hp..........3/4
Table Feed Cross Hp..........1/2
Table Rapid Vertical Hp..........1/2
Feed Motor Hp..........1/8
Machine Dimensions (LxWxH)..........68.5 x 63.6 x 79
Weight..........5,390
Machine Features:
X Axis (left/right) and Y Axis (in/out) gearbox is controlled at the operator friendly control panel
Mechanical rapid traverse on X, Y & Z axis
Pendant operator panel for ease of operation.
High quality meehanite casting for superior rigidity and wear resistance
All gears and shafts are hardened and ground
Large 50” x 11.8” (1270 x 300mm) angling table with 3 T-slots
All slide ways and table are hardened and ground
Turcite coated X,Y axis for wear resistance
Clamps on all square slide ways
Horizontal manual drawbars
Automatic coolant system and coolant pump
Halogen worklight
Tool box and service tools
CE Electrics for reliability
A one year warranty backed by Clausing Service Center dedicated to support our customers with parts and service
