New 2025 Clausing 6VHS Horizontal - Vertical Combo Mill

Machine Style..........Horizontal-Vertical Combo
Table Area (in)..........11.81 x 59
Total Load Capacity (lbs.)..........950
No. of T-slots..........3
Distance Between T-Slots (in)..........2.75
T-slot Size (in)..........0.629
X Manual Longitude (in)..........39.3
Y Manual Cross (in)..........14.9
Z Manual Knee (in)..........18.11
X Feed Range (in/min)..........0.94-27.8 (12 step)
X Rapid Range (in/min)..........75
Knee Rapid Range (in/min)..........26.77
Spindle Taper (Vertical)..........NMTB 40
Speed (Vertical)..........16
Spindle RPM (Vertical)..........75-3800
Swiveling Angle (Right and Left (Vertical)..........45°
Quill Travel (Vertical) (in)..........5.5
Quill Feeds (Vertical) (in/rev)..........0.0013/0.0027/0.0055
Spindle Nose to Table (Vertical)..........3.54-19.68
Ram Swivel (Vertical)..........360°
Cross Travel Ram (Vertical)..........17.7
Spindle Taper (Horizontal)..........NMTB 40
Speed Steps (Horizontal)..........9
Spindle Speed RPM (Horizontal)..........90-1320
Spindle to Bottom of Ram (Horizontal) (in)..........6.29
Spindle Center to Table (Horizontal) (in)..........0-18.1
Vertical Spindle Hp..........5
Horizontal Spindle Hp..........5
Table Feed Longitudinal Hp..........2
Table Feed Cross Hp..........1/2
Table Rapid Vertical Rapid Traverse Hp..........1
Coolant Pump Hp..........1/8
Machine Dimensions (LxWxH)..........76.7 x 63.6 x 79
Weight (lbs.)..........4,620

Machine Features:
High quality meehanite casting for superior rigidity and wear resistance
Large control panel operators box for ease of operation
X/Y Axes ballscrews
X Axis gear box power feed system
Y Axis power motor 1/2Hp w/ 1Hp inverter drive
Power knee elevation
NMTB 40 Spindles
Coolant pump system (no pan)
Auto lube pump
Halogen work light
1” Arbor and 2 Arbor supports
Manual drawbars
Tool box and service tools
A one year warranty backed by Clausing Service Center dedicated to support our customers with parts and service
