The Clausing Kalamazoo MSD2031CNC Horizontal Miter Bandsaw offers precision with its CNC capabilities, 7.5 hp motor, and automated features. Designed for efficiency, it cuts up to 20" rounds and 16"x31" rectangles with variable speeds and a swivel saw head.
Specifications:
Machine Style..........CNC Bandsaw
Drive Type..........Variable Inverter Drive
Maximum Capacity Round (inch)..........20
Maximum Capacity Rectangle (inch)..........16 x 31
Voltage..........230
Phase..........3
Coolant System..........Yes
Angular Cuts at 45 Degrees (inch)..........16 x 21
Blade Size..........2” x .05” x 260”
Blade Speeds (SFPM)..........66 – 328
Blade Guide Type..........Carbide
Motor Horsepower..........7.5
Machine Features:
• Swivel saw head mitering from 90° to 60° Left to 45° Right
• Planetary Gear Box reducer producing better efficiency then worm gear drives. Offers high transmission efficiency and stable blade tension
• Precision feed pressure & feed rate dual valve system
• Inverter controlled infinitely variable speed
• Fanuc CNC technology programmable up to 100 different jobs
• Carbide blade guides with roller bearings
• Save-A-Blade automatic vise retracting after material cut-off, reducing abrasion and improving blade life
• 5.7” HMI touch screen incorporating readout on blade speed, blade life, feed vise position and error code display for self-diagnostics
• Integrated coolant system
• Conveniently designed control station
• Easily recall and execute stored programs
• Maintenance reminder signals
• Electrical components located inside the control box with main lockout disconnect
• Automatic kerf loss compensation and automatic multiple indexing up to 393.6”
• Save-A-Blade automatic vise retracting after material cut-off, reducing abrasion and improving blade life
• Programmable cutting rates and blade speeds to achieve best cutting performance
• 2 Year limited warranty
