New 2025 Clausing Kalamazoo MSD2031NC Horizontal Miter Bandsaw

Specifications:
Machine Style..........Automatic
Drive Type..........Variable Inverter Drive
Maximum Capacity Round (inch)..........20
Maximum Capacity Rectangle (inch)..........16 x 31
Voltage..........230
Phase..........3
Coolant System Yes
Angular Cuts at 45 Degrees (inch)..........16 x 21
Blade Size..........2” x .05” x 260”
Blade Speeds (SFPM)..........66 – 328
Blade Guide Type..........Carbide
Motor Horsepower..........7.5

Machine Features:
• The swivel saw head allows cutting at any angle between 90° (straight cut) and 30° (miter cut)
• Precision feed pressure & feed rate dual valve system
• Inverter controlled infinitely variable speed
• Smart NC-100 technology programmable up to 100 different jobs
• Carbide blade guides with roller bearings
• Automatic shutoff after preset number of cuts or when out of stock
• 5.7” HMI touch screen incorporating readout on blade speed, blade life, feed vise position and error code display for self-diagnostics
• Integrated coolant system
• Conveniently designed control station
• Easily recall and execute stored programs
• Electrical components located inside the control box with main lockout disconnect
• Automatic kerf loss compensation and automatic multiple indexing up to 393.6”
• Save-A-Blade automatic vise retracting after material cut-off, reducing abrasion and improving blade life
• 2 Year limited warranty
