New 2025 Blaze Max Laser OPTX 1K LF Package Productive Robotics
Have one to sell?
ConditionNew
100 available
New
Introducing the New 2025 Blaze Max Laser OPTX 1K LF Package from PRODUCTIVE ROBOTICS!
Featuring a 7-axis collaborative Blaze Laser robot, it offers a 85" reach, and no programming requirement.
Blaze Laser OPTX 1K LF Package
Includes:
• 1 Blaze Max Robot
• 1 Rolling Stand
• 1 Miller OptX 1k Laser
• 1 Miller Cobot Kit
• 1 Miller Wire Feeder
• 1 Miller Startup Kit
• 1 Enclosed Welding Cell
• 1 Blaze Welding Software
• 1 4' x 8' Siegmund Table
• 1 No Programming Teach Tablet
Dimensions
Overall:
Table Height: 914 mm (36”)
Work Surface: 1060 mm x 1,244 mm (41.75” x 48”)
Wire Drive:
• Wire Feed Delivery Length: 10 ft. (3 m) Optional: 15 ft. (5 m)
• LightWELD Interface: Low Voltage enable signal cable
• Wire Feed Speed Range: 0.5 - 230 ipm (1 - 600 cm/min)
• Compatible Wire Diameters: 0.030” – 0.063” (0.8 mm - 1.6 mm)
• Wire Reel Capacity: Up to 30 lbs. (12” diameter)
Compatible Wire Materials:
Steel, Stainless Steel, Aluminum, Copper, Nickel
Power Requirements: 115 - 230V 50/60 Hz
LightWeld® Welder:
• Welding Only: LightWELD 1500
• Welding & Cleaning: LightWELD 1500 XC
• Laser Power Output: Up to 2 kW
• Input Power: 200-240VAC, 3PH, 50/60 Hz, 24 Amps
• Presets: Up to 100
• Process Gas: Argon/Nitrogen
• Working Pressure: 15-30 psi (1-2 Bar)
• Cooling: Air-Cooled (No External Chiller Required)
Introducing the New 2025 Blaze Max Laser OPTX 1K LF Package from PRODUCTIVE ROBOTICS!
Featuring a 7-axis collaborative Blaze Laser robot, it offers a 85" reach, and no programming requirement.
Blaze 7-axis welding cobots provide a safe, far less expensive alternative to traditional automation, enabling fabrication shops of all sizes to scale operations, reduce costs, and stay competitive. Blaze cobots allow welders to focus on higher value work and setups while automation handles the tedium of repetitive welding.
Operation is 100% intuitive with zero programming and lightning fast to learn. It only takes minutes to teach Blaze your first weld and it's easy to get started - no robot experience required. Blaze sets up in under an hour and starts boosting your shop productivity on day one.
Get more weldments done in a single setup with 7-Axis, versus having to re-fixture with a 6-Axis robot. Only a 7-Axis robot can reach around all sides of fixtures and workpiece obstacles without restriction.
Blaze is the ultimate in ease-of use —you can teach a job faster than doing it once by hand and trust Blaze to repeat the job with clean, precise welds every time.
Blaze has the unique feature of being able to quickly and easily remove the torch to do tacking or complex welds by hand. There’s also a live trigger on the torch for spot welding and more.
Use the control handle to physically teach Blaze to weld, without programming. Show Blaze the start and end of welds, tack points, circles or any complex shape at the touch of a button.
Stay agile with fast short run changeovers and zero reprogramming on repeat jobs. Blaze adds efficiency to high mix or low mix, short runs or long runs, and can be repurposed quickly to meet changing demands.
Imperial
| # Axis | 7 |
| Horizontal Reach | 85" |
| Reach | 85" |
| Repeatability | +/- 0.1mm ~ .004" |
| Speed | 0-2+ m/s |
| IP Class | 61 |
| Joint Ranges | +/- 360 Degrees (all) |
| Programming | No Programming Learns by Demonstration |
| Safety | ISO 10218-1 Compliant ; Power and force limited |
| Robot Mounting Flange Diameter | 220 mm: OB7 |
| Gripper Mounting Flange: | ISO 9409-1-50-4-M6 |
| Working Temperature: | 0-37 Celsius 32-100 Fahrenheit |
| Power Source | 100 - 240 VAC 50-60hz |
| Uninterruptible Power: | 10 minutes (robot stopped) for moving robot to new location |
| Power Consumption: | OB7: 90-650 W OB7-Max: 90-1000W dependent on speed and payload |
| Linear Speed: | 2m/s max (Dependent on position) |
| Table Height | 36 |
| Work Surface | 41.75"x 48" |
| Welder | Miller OptX 1kW |
| Dimensions | 97" x 75" x 86" |
Blaze Laser OPTX 1K LF Package
Includes:
• 1 Blaze Max Robot
• 1 Rolling Stand
• 1 Miller OptX 1k Laser
• 1 Miller Cobot Kit
• 1 Miller Wire Feeder
• 1 Miller Startup Kit
• 1 Enclosed Welding Cell
• 1 Blaze Welding Software
• 1 4' x 8' Siegmund Table
• 1 No Programming Teach Tablet
Dimensions
Overall:
Table Height: 914 mm (36”)
Work Surface: 1060 mm x 1,244 mm (41.75” x 48”)
Wire Drive:
• Wire Feed Delivery Length: 10 ft. (3 m) Optional: 15 ft. (5 m)
• LightWELD Interface: Low Voltage enable signal cable
• Wire Feed Speed Range: 0.5 - 230 ipm (1 - 600 cm/min)
• Compatible Wire Diameters: 0.030” – 0.063” (0.8 mm - 1.6 mm)
• Wire Reel Capacity: Up to 30 lbs. (12” diameter)
Compatible Wire Materials:
Steel, Stainless Steel, Aluminum, Copper, Nickel
Power Requirements: 115 - 230V 50/60 Hz
LightWeld® Welder:
• Welding Only: LightWELD 1500
• Welding & Cleaning: LightWELD 1500 XC
• Laser Power Output: Up to 2 kW
• Input Power: 200-240VAC, 3PH, 50/60 Hz, 24 Amps
• Presets: Up to 100
• Process Gas: Argon/Nitrogen
• Working Pressure: 15-30 psi (1-2 Bar)
• Cooling: Air-Cooled (No External Chiller Required)
