Introducing the NEW Flow Mach 500 4080 Waterjet Cutter by FLOW. Featuring precise accuracy, dynamic cutting heads, and versatile pumps up to 94,000 psi. Enjoy seamless operation with a touchscreen control and expansive 4m x 8m work envelope. Ideal for precision tasks.
Specifications
Rapid Traverse Maximum.......... 700in./min / 17.8m/min
Linear Positional Accuracy.......... (± .0005 in) (± .0127 mm)
Repeatability.......... (± .0008 in) (± .02 mm)
Cutting Heads..........
• Pure Waterjet
• Standard Abrasive Waterjet
• Dynamic Waterjet
• Dynamic Waterjet XD
Secondary Z-Axis.......... Pure Waterjet Standard, Abrasive Waterjet, Programmable Z-axis
Z-Axis Travel.......... (12 in, 24 in) (305 mm, 610 mm)
Pumps..........
HyPlex Prime
• 60,000 psi [4,150 bar]
• 30 hp, 50 hp
MotoJet
• 60,000 psi [4,150 bar]
• 30 hp, 50 hp
MotoJet X
• 60,000 psi [4,150 bar]
• 30 hp, 50 hp
HyperJet
• 94,000 psi [6,500 bar]
• 30 hp, 50 hp, 100 hp
Control.......... Touch screen / Roll-Around Operator Station
Software Options.......... FlowXpert Infinity / FlowMaster
Work Envelope.......... Mach 500 4080: 4 m x 8 m
Acceleration.......... 0.1g
Ballbar Circularity.......... (+/- .0025) / (+/- .0635)
Introducing the NEW Flow Mach 500 4080 Waterjet Cutter by FLOW. Featuring precise accuracy, dynamic cutting heads, and versatile pumps up to 94,000 psi. Enjoy seamless operation with a touchscreen control and expansive 4m x 8m work envelope. Ideal for precision tasks.
T.R. Wigglesworth Machinery Company is proud to offer this Flow Mach 500 4080 Waterjet.

Driven by extensive research and customer feedback, the Mach 500 is the fastest, quickest, most accurate waterjet by design. Designed with the operator in mind, the system is built for production. No other waterjet is quite like this.

With the modern architecture, precision motion, and Flow's leading ultrahigh-pressure technology at the core, the Mach 500 is unmatched in speed and accuracy. Paired with Dynamic XD and Compass, there is no waterjet that can compare.

The Mach 500 is equipped with top-of-the-line components from leading machine tool suppliers for the machine drive, precision motion system, motion control, and solid model software to create a machine that is the quickest, and most accurate on the market.

The ultrahigh-pressure pump technology, machine control, cutting heads, industry-leading software, and advanced wrist articulation pioneered by Flow are the foundation of the Mach 500.
Imperial
| Pump Output | 94,000 PSI |
| X | 157.5" |
| Y | 315" |
| Z | 24" |
| Table Size-W | 157.5" |
| Table Size-L | 315" |
| Power | 100 hp |
| Control | CNC |
Specifications
Rapid Traverse Maximum.......... 700in./min / 17.8m/min
Linear Positional Accuracy.......... (± .0005 in) (± .0127 mm)
Repeatability.......... (± .0008 in) (± .02 mm)
Cutting Heads..........
• Pure Waterjet
• Standard Abrasive Waterjet
• Dynamic Waterjet
• Dynamic Waterjet XD
Secondary Z-Axis.......... Pure Waterjet Standard, Abrasive Waterjet, Programmable Z-axis
Z-Axis Travel.......... (12 in, 24 in) (305 mm, 610 mm)
Pumps..........
HyPlex Prime
• 60,000 psi [4,150 bar]
• 30 hp, 50 hp
MotoJet
• 60,000 psi [4,150 bar]
• 30 hp, 50 hp
MotoJet X
• 60,000 psi [4,150 bar]
• 30 hp, 50 hp
HyperJet
• 94,000 psi [6,500 bar]
• 30 hp, 50 hp, 100 hp
Control.......... Touch screen / Roll-Around Operator Station
Software Options.......... FlowXpert Infinity / FlowMaster
Work Envelope.......... Mach 500 4080: 4 m x 8 m
Acceleration.......... 0.1g
Ballbar Circularity.......... (+/- .0025) / (+/- .0635)
