FERMAT WPT 130 L New Model Horizontal Boring, Milling, & Drilling Machine for Quick Delivery
Have one to sell?
ConditionNew
1 available
New
Introducing the FERMAT WPT 130 L, a new CNC universal table-type horizontal boring mill. Boasting a 5.12" spindle, 157.48" table travel, 49.6 hp, and 3400 max RPM, it's designed to handle complex machining tasks with precision and power. Quick Delivery, High value machine. Reach out for your proposal today.
======================================================================
PARAMETER METRIC VALUE.......... IMPERIAL VALUE
======================================================================
Table travel - X-axis.................. 4000 mm.......... 157.48 in
Headstock travel - Y-axis.............. 2500 mm.......... 98.43 in
Column travel - Z-axis................. 1500 mm.......... 59.06 in
Spindle travel - W-axis................ 800 mm.......... 31.50 in
Spindle diameter....................... 130 mm.......... 5.12 in
Maximum spindle speed.................. 3400 RPM.......... 3400 RPM
Working cutting feed rate (X, Y, Z, W). 1-4000 mm/min.......... 0.04-157.48 in/min
Rapid traverse rate (X, Y, Z).......... 10000 mm/min.......... 393.70 in/min
Rapid traverse rate (W-axis)........... 6000 mm/min.......... 236.22 in/min
"In stock now"
Introducing the FERMAT WPT 130 L, a new CNC universal table-type horizontal boring mill. Boasting a 5.12" spindle, 157.48" table travel, 49.6 hp, and 3400 max RPM, it's designed to handle complex machining tasks with precision and power. Quick Delivery, High value machine. Reach out for your proposal today.
Imperial
| Spindle Size | 5.12" |
| X-Horiz Tvl of Table | 157.48" |
| Y-Vert Tvl of Head | 98.43" |
| Power | 49.6 hp |
| RPM | 3,400 RPM |
| Table-W | 86.61" |
| Table-L | 70.87" |
| Spindle Tvl. | 31.49" |
| Weight | 45,000 to 65,000 lbs |
======================================================================
PARAMETER METRIC VALUE.......... IMPERIAL VALUE
======================================================================
Table travel - X-axis.................. 4000 mm.......... 157.48 in
Headstock travel - Y-axis.............. 2500 mm.......... 98.43 in
Column travel - Z-axis................. 1500 mm.......... 59.06 in
Spindle travel - W-axis................ 800 mm.......... 31.50 in
Spindle diameter....................... 130 mm.......... 5.12 in
Maximum spindle speed.................. 3400 RPM.......... 3400 RPM
Working cutting feed rate (X, Y, Z, W). 1-4000 mm/min.......... 0.04-157.48 in/min
Rapid traverse rate (X, Y, Z).......... 10000 mm/min.......... 393.70 in/min
Rapid traverse rate (W-axis)........... 6000 mm/min.......... 236.22 in/min
"In stock now"
