CNC Horizontal Boring Mill with Full B-Axis Rotary Table

The FEMCO BMC series supports table load capacities up to 40,000 lbs depending on the model. The BMC-100HT and BMC-110R3 both accommodate up to 40,000 lbs, making them suitable for very large castings, weldments, and structural components found in heavy manufacturing and energy sectors.

All machines in this lineup use FANUC CNC control systems, including the Fanuc OiMF, Fanuc 31i-B, and the advanced FANUC Artificial Intelligence Contour Control (AICC) available on the BMC-100HT. These controls deliver high precision, reliable automation, and compatibility with standard G-code programs used across the industry.

X-axis travels range from 55.12 inches on the BMC-110R1 up to 157.4 inches on the BMC-135TNL. Mid-range models like the BMC-110R3 and BMC-110T3 offer up to 118.11 inches of horizontal table travel, providing flexibility to accommodate workpieces of varying lengths and configurations.

The BMC series offers spindle power from 35 HP to 50 HP with geared head spindles. Speed ranges vary by model: the BMC-100HT reaches up to 8,000 RPM for high-speed precision work, while the BMC-110R and BMC-135T series operate up to 2,500–3,000 RPM for heavy-duty cutting with maximum rigidity and torque.

Yes. All FEMCO CNC Horizontal Boring Mills sold by T.R. Wigglesworth Machinery Company include delivery, installation, and training services as part of the purchase. This ensures your machine is commissioned correctly and your operators are fully trained before production begins. Contact us for specific timeline and logistics details for your location.

These machines are widely used in heavy manufacturing, aerospace and defense, energy and power generation, and precision fabrication. They are particularly well suited for machining large castings, complex welded frames, gearboxes, engine housings, and structural weldments that require multi-axis precision and high table load capacity in a single setup.
