Engine Lathe for Maintenance and Repair Operations

A variable speed engine lathe, like the 8044VSJ, uses an AC inverter drive to deliver infinitely adjustable RPM within defined ranges — ideal for diverse materials and cuts without gear changes. A geared head lathe provides fixed speed steps via a precision gear train, offering high torque and durability for heavy-duty or repetitive production turning.

Yes. Both the Clausing C-Series and the 8044VSJ model feature a universal gearbox supporting inch, metric, diametral pitch (D.P.), and module pitch (M.P.) threading. The C-Series covers a wide threading range across all models, while the 8044VSJ offers 73 inch pitches, 51 metric pitches, and 27 module and diametral pitches.

Clausing engine lathes span a wide power range to suit different MRO needs. The 8044VSJ features a 10 HP spindle motor, while the C-Series spans from 3 HP on smaller models up to 50 HP on the largest configurations, accommodating everything from light maintenance work to heavy-duty industrial turning.

Yes. The Clausing C-Series engine lathes are specifically rated for oil field and marine applications. With swing over bed up to 70 inches, spindle bores up to 24.02 inches, and distances between centers up to 482 inches, they accommodate large components typical in oil country tubular goods (OCTG) and shipbuilding environments.

The Clausing C-Series includes a one-year parts and labor warranty backed by Clausing's Service Center. The 8044VSJ includes a 4-year parts and labor warranty on the AC inverter drive. Both are supported by a parts inventory of over 80,000 items, with 95% of orders shipped within 24 hours, plus on-site and phone technical support.

A gap bed engine lathe features a removable section of the bed near the headstock — called the gap plate — that, when removed, allows larger-diameter workpieces such as face plates, flanges, or pulleys to be turned. On the Clausing C-Series and 8044VSJ, the gap bed extends swing capacity significantly beyond the standard swing over bed measurement.
