Surface Grinder for Hardened Steel Parts

CBN (cubic boron nitride) is the premier abrasive for hardened tool steels, particularly those above 60 HRC. It maintains hardness at high temperatures and resists chemical reactions with ferrous materials. For lower-hardness tool steels, white aluminum oxide or pink aluminum oxide abrasives are cost-effective alternatives that provide a good surface finish with minimal workpiece heat damage.

For extremely hard materials such as hardened die steels, HSS, and carbide-tipped tooling, CBN and diamond grinding wheels are the optimal choices. CBN wheels are preferred for ferrous materials due to their chemical compatibility, while diamond wheels are better suited for non-ferrous hard materials like carbide. Both are available in resin, vitrified, and electroplated bond systems depending on the application.

Clausing CSG series surface grinders are available with table sizes ranging from 6" x 18" up to 20" x 40". This wide range accommodates everything from small toolroom components to large production parts. The CSG3A1224, for example, offers a 12" x 24" table suited for mid-size hardened steel components in job shop and industrial environments.

Manual-hydraulic surface grinders use hydraulic power for longitudinal table movement with operator-controlled crossfeed, offering tactile control ideal for skilled machinists and varied workpieces. Automatic CNC models (ASD series) add a Delta PLC controller with a 7.2" color touch screen, enabling programmable head positioning, auto-cycles, and repeatable results for higher-volume production environments.

Clausing CSG series grinders offer spindle speeds from 1,750 RPM to 3,450 RPM and spindle motor horsepower ranging from 2 hp to 7.5 hp across the full model range. The CSG3A1224 specifically runs at 1,750 RPM with a 5 hp spindle motor, providing ample power for consistent stock removal on hardened steel surfaces without deflection.

All Clausing surface grinders include a 1-year limited manufacturer's warranty. T.R. Wigglesworth Machinery Company supports every purchase through an independently operated Clausing Service Center stocking over 80,000 parts, with 95% of orders shipped within 24 hours. Highly qualified technicians are also available for both phone consultation and on-site support visits.
